milling machining centers - vertical
HURCO VMX 42
Catalog no. 102011
Built in 2009,
Control: Hurco Ultimax 4. Machine has 24 positions in the ATC, many toolholders
with the machine, vices, a FLIP-POD Vacuum clamping system, a zero point
clamping system SPEEDY classic 3.book and a Elbo Controlli NIKKEN tool set
system.
| x-travel |
|---|
| 1060 mm |
| y-travel |
|---|
| 610 mm |
| z-travel |
|---|
| 610 mm |
| table-size |
|---|
| 1220 x 510 mm |
| spindle diameter |
|---|
| 80 mm |
| tool taper |
|---|
| SK 40 |
| spindle turning speed - stepless |
|---|
| 10- 10000 U/min |
| feeds |
|---|
| 1- 30000 mm/min |
| rapid traverse |
|---|
| 30000 mm/min |
| spindle drive |
|---|
| 15 kW |
| connected load |
|---|
| 30 kVA |
| weight of the machine ca. |
|---|
| 6,5 t |
| dimensions of the machine ca. |
|---|
| 3 x 3,2 x 2,7 m |
Additional Information
Country of origin Taiwan, Current location warehouse Ennepetal,
Delivery as per agreement, Quotation ex stock, free on truck,
Price on request
